Boeing B737 NG Electrical Взлом 5.7

Скриншоты

Описание

The Boeing 737 NG Interactive Electrical Diagram is a completely interactive training aid. The interactive diagram allows the user to learn the electrical system by manipulating switches and visualize the cause and effect.

The user can simulate a failure which allows the user to use a QRH to work through each failure.

DISCLAIMER: The Boeing 737 NG Interactive Electrical Diagram is to be used as a reference only and can not be used for flight or to replace formal training.

*iPhone 4: Do not use on an iPhone 4 as the screen layout has not been customized for this device.

История обновлений

5.7

2020-04-04

- General bug fixes

5.5.1

2017-03-10

- Added an iPhone version

5.4

2017-02-23

- Updated battery charge line to reflect better placement in relation to the battery

5.3

2017-01-05

- Changed load shed logic with single gen operation

5.2

2016-12-16

- Added Engine, APU, and GPU on/off switches to the main display

- Fixed Bat Bus Norm Relay (K2) operation with the Bat Switch off

5.1

2016-10-11

- Updated Bus Transfer Switch to work correctly when OFF and the APU switches engaged.

4.2

2016-02-03

- Fixed Battery Switch must be on for Battery Bus to receive power.

4.1

2015-08-31

- Update to DC meter to reflect TR1 & TR2 voltage read through DC Bus 1 & 2.

4.0

2015-03-06

- Diagram re-designed to better show the standby electrical system

- Multiple new failure scenarios added

3.3

2014-05-06

- Bug fix for iPad Air

3.2

2014-04-27

- Minor bug fixes

3.1

2014-03-22

- Fixed minor bug with Static Inverter display

3.0

2014-03-07

- Updated graphics

- Fixed APU shutoff when battery switch OFF

2.1

2013-12-05

- Addition of a interactive description on different parts of the electrical system.

- Addition of multiple electrical system failures.

- Corrected GPU offline with BAT Switch OFF.

1.2

2013-11-27

Minor change to diagram functionality.

1.1

2013-10-22

- Minor corrections to diagram including Battery Discharge indication.

- Addition of power up tutorial.

- Addition of Overhead Electrical Panel Indications explanation.

1.0

2013-09-28
