Description

NAVDESK

"A new dimension to your navigation experience"

Get everything out of your Sailmon Instrument system with Navdesk.
Control your instruments from every device anywhere on the boat.

Some of the features:
Control each Instrument individually or as a group
Control in and outputs, colors, text size, name etc.
Backlight control
Calibrate all your sensors
Ping the start line
set the name of your ship and choose to be on LOGS
...and much more

Version history

3.5.3

2023-07-25

Bug fixes

3.5.2

2023-04-07

– New configuration page specific to Modbus inputs / outputs
– New Alarms page for configuring built-in Depth and Wind alarms
– ScriptTool supports setting of system alarms
– Fix the selected screen layout when switching through presets in NavDesk
– Fix value name shown incorrectly when configuring alarms

3.5.0

2022-04-20

Depth alarms configurable in NavDesk
Make Up / Downwind context switch limits adjustable
Allow hiding description for more elements types
Expand factor limits for Leeway calculation formula
3D TWS calibration table not limited to Downwind any more
Global unit selection for Load types (N/kg/Tons)
Show name of offline sensors in calibration pages
Fix broken scrolling down for screen to configure
Fix broken configuration of some gauge elements
Custom scripting of any E4 behavior (ask Sailmon support)
Read A+T Load Cell data from NMEA2000 messages
Read multiple Cyclops Load Cell instances from single NMEA device
Wind from external processor can be used for context switching
Reduced delay for context switching
Improved backlight adjustments by Buttonbox
Fix backlight dimming to levels below 1%
Fix a duplicate element in one portrait layout
Fix global unit selection not applied
Fix gauges not showing any digits
Fix value colors not always shown correctly

3.4.1

2021-07-28

bug fixes

3.4.0

2021-03-08

E4 / Screen Software
– New direction indicator option for Value elements
– Dew Point support from various input
– Floating point support for Modbus sensors
– Read more GPS quality flags over NMEA0183
– Custom Expedition channel output available for E4 Silver
– Fix incorrect handling of negative timezone offsets
– Several bug fixes and performance improvements

NavDesk and Apps
– Individually configurable Backlight groups
– New button actions: Backlight control and individual sleep/standby modes
– Fix possible NavDesk hangs when losing E4 connection
– Improved stability on recent Windows 10 versions

3.3.1

2020-08-30

Bug fixes

3.3.0

2020-08-08

New element listing all active Alarms, Support general alarms triggered by Buttons or via Modbus
Allow Leeway calculation from Heading and COG, Avoid flickering of the Wind plot on Sailmon displays
Do not overwrite Race timer of B&G on NMEA2000
Fix sending Pixel angle data over NMEA2000 to B&G
Fix sending raw sensor data between E4 and apps

3.2.9

2019-12-21

Bug fixes and improvements

3.2.8

2019-10-28

Bug fixes and improvements

3.2.6

2019-09-04

Bug fixes

3.2.5

2019-08-30

fixed scaling issues for iPhone

3.2.4

2019-07-21

Bug fixes

3.2.3

2019-06-13

Bugfixes

3.2.2

2019-05-16

Bug fixes and added wind shear offset setting

3.2.0

2019-04-04

These are the main new features:
- Login no longer required
- registration with LOGS now works by scanning a QR code
- preset names can be changed
- support for B&G custom channels on NMEA2000
- USB Wifi now supports updating the system
- Garmin NMEA2000 output improved
- and many more bug fixes and improvements

3.1.8

2019-01-25

Heading calibration with custom tables
Linear calibration with custom tables
Man Overboard now is fully integrated into Sailmon
Support for all 18 Garmin channels on NMEA2000
Support for Velocity Made on Course (VMC)
New button actions: MOB, Sleep and Standby modes
Preset switching when boat is Docked or in MOB

3.1.7

2018-11-02

Bug fixes

3.1.5

2018-09-16

New TWA and TWS 3D wind calibration tables with 3D graphical feedback
and bug fixes

3.1.4

2018-09-05

NavDesk can now be used to update all your Sailmon devices, even when not online
Improved startup time and app performance

3.1.0

2018-05-23

Many small improvements and bugfixes

3.0.8

2018-04-28

Calibration tables for Load Cells, including graphs
Improved status feedback when connecting to LOGS
Removed Turn Rate offset calibration
Background color of virtual screens can be changed
Fix changing of data output mapping from mobile devices
Fix ScreenView crash when chosen instrument was deleted

Output the user-defined names in Garmin Custom NMEA2000 channels
New uncalibrated output values for: BS, Course, Heading, Heel, Pitch
New output value: Predicted Course
Change default unit for (Load Cell) forces to Tonnes
Fix hang of Sailmon LOGS in unstable networks

3.0.0

2018-01-03

The New NavDesk major release 3.0.0 now has a dashboard that helps you get an overview of the entire system at a glance
The menu system has been redesigned to help you do more in less time
3D calibration of boat speed now has a 3D visualisation with all other 3D calibrations to folow

2.1.5

2017-06-05

Bug fixes and performance enhancements

2.1.3

2017-02-27

Fixed bugs and improved performance

2.1.1

2016-12-20

NavDesk now has support for our new E4 processor.
It lets you register your E4 based Sailmon system into the Sailmon cloud server.
It now has the ability to create virtual screens that can be displayed with all wireless devices.
There have been made many improvements in overall stability and especially in network stability.
